menu.c File Reference

Menu implementation file. More...

#include "menu.h"
#include "common.h"
#include "init.h"
#include "ssd1309.h"
#include "err.h"
#include "configuration.h"
#include "log.h"
#include "cmd.h"

Include dependency graph for menu.c:

Go to the source code of this file.

Classes
struct	menu_handle_s
	Internal structure representing a single menu instance. More...
struct	internal_state_s
	Internal state of the SysTick driver. More...

Functions
static ERR_te	menu_selectable_run (MENU_HANDLE_ts *menu_handle)
	Renders a MENU_TYPE_SELECTABLE menu to the display.
static ERR_te	menu_dataview_run (MENU_HANDLE_ts *menu_handle)
	Renders a MENU_TYPE_DATA_VIEW menu to the display.
static ERR_te	menu_cmd_info_handler (uint32_t argc, char **argv)
	CLI handler for the "info" command. Logs the names of all active menu handles.
static ERR_te	menu_cmd_scroll_handler (uint32_t argc, char **argv)
	CLI handler for the "scroll" command. Scrolls a named menu and re-renders it.
ERR_te	menu_init_subsys (void)
	Initializes the menu subsystem.
ERR_te	menu_deinit_subsys (void)
	Deinitializes the menu subsystem.
ERR_te	menu_start_subsys (void)
	Starts the menu subsystem.
ERR_te	menu_stop_subsys (void)
	Stops the menu subsystem.
ERR_te	menu_init_handle (MENU_CFG_ts *menu_cfg, MENU_HANDLE_ts **menu_handle_o)
	Initializes and registers a menu handle.
ERR_te	menu_run_handle (MENU_HANDLE_ts *menu_handle)
	Renders a single menu to the display.
ERR_te	menu_run_handle_all (void)
	Renders all registered menus to the display.
ERR_te	menu_get_selected_option (MENU_HANDLE_ts const *menu_handle, char *selected_option_o)
	Retrieves the string of the currently highlighted option.
ERR_te	menu_scroll (MENU_HANDLE_ts *menu_handle, VERTICAL_DIR_te vertical_dir)
	Moves the menu selection cursor by one step in the given direction.
ERR_te	menu_get_prev_menu (MENU_HANDLE_ts *menu_handle, MENU_HANDLE_ts **prev_menu_handle_o)
	Pops and returns the previous menu from the navigation history stack.
ERR_te	menu_set_prev_menu (MENU_HANDLE_ts *menu_handle, MENU_HANDLE_ts *prev_menu_handle)
	Pushes a menu onto the navigation history stack of another menu.

Variables
static struct internal_state_s	internal_state = { 0 }
	Singleton instance of the menu subsystem internal state.
static CMD_INFO_ts	menu_cmds []
	Table of CLI commands registered by the menu subsystem.
static CMD_CLIENT_INFO_ts	menu_cmd_client_info
	Registration descriptor passed to the command subsystem.

Detailed Description

Menu implementation file.

Author

github.com/Baksi675

Version

0.1

Date

2025-12-21

Copyright

Copyright (c) 2025

Definition in file menu.c.

Variable Documentation

internal_state

struct internal_state_s internal_state = { 0 }

static

Singleton instance of the menu subsystem internal state.

Definition at line 109 of file menu.c.

{ 0 };

menu_cmds

CMD_INFO_ts menu_cmds[]

static

Initial value:

= {
    {
        .name = "scroll",
        .help = "Scroll up or down, usage: menu scroll <menu> <up|down>",
        .handler = menu_cmd_scroll_handler
    },
    {
        .name = "info",
        .help = "Shows menu information, usage: menu info",
        .handler = menu_cmd_info_handler
    }
}

Table of CLI commands registered by the menu subsystem.

Registered with the command subsystem via menu_cmd_client_info during menu_init_subsys.

Definition at line 126 of file menu.c.

                                 {
    {
        .name = "scroll",
        .help = "Scroll up or down, usage: menu scroll <menu> <up|down>",
        .handler = menu_cmd_scroll_handler
    },
    {
        .name = "info",
        .help = "Shows menu information, usage: menu info",
        .handler = menu_cmd_info_handler
    }
};

menu_cmd_client_info

CMD_CLIENT_INFO_ts menu_cmd_client_info

static

Initial value:

= {
    .cmds_ptr = menu_cmds,
    .num_cmds = sizeof(menu_cmds) / sizeof(menu_cmds[0]),
    .name = "menu",
    .log_level_ptr = &internal_state.log_level
}

Registration descriptor passed to the command subsystem.

Bundles the command table, its size, the subsystem name prefix used on the CLI, and a pointer to the runtime log-level variable.

Definition at line 146 of file menu.c.

                                                 {
    .cmds_ptr = menu_cmds,
    .num_cmds = sizeof(menu_cmds) / sizeof(menu_cmds[0]),
    .name = "menu",
    .log_level_ptr = &internal_state.log_level
};
